1.Voltage电压: 335Vdc

Current (Irms)电流: 167A

Peak Current峰值电流 (Ip): 300A /30S

L  Inductance电感：≥12uH

X  Capacitance容量:1nF

Y  Capacitance容量: 2*0.47μF+2*4.7nF++2*1 nF

Operation Temperature工作温度: -40 +  105ºC

Flame retardant阻燃：UL-94V0

2.Voltage电压: 400Vdc

Current (Irms)电流: 225A

L  Inductance电感：≥40uH

X  Capacitance容量:330nF+680nF+1nF

Y  Capacitance容量: 2*0.1μF+2*0.22 μF+2*0.15 μF++2*2.2 nF

Operation Temperature工作温度: -40 +  85ºC

Flame retardant阻燃：UL-94V0

3.Voltage电压: 400Vdc

Current (Irms)电流: 225A

L   Inductance电感：≥8uH

Operation Temperature工作温度: -40 +  85ºC

Flame retardant阻燃：UL-94V0

4.Voltage电压: 400Vdc

Current (Irms)电流: 260A

Peak Current峰值电流 (Ip): 600A /10S

L  Inductance电感：2uH+60uH

X  Capacitance容量:2.2μF+2.2nF

Y  Capacitance容量: 2*0.22μF+2*270nF

Operation Temperature工作温度: -25 +  100 ºC

Flame retardant阻燃：UL-94V0

5.Voltage电压: 440Vdc

Current (Irms)电流: 170A

L  Inductance电感：5uH+32uH

X  Capacitance容量:470nF+330nF+100nF

Y  Capacitance容量: 2*4.7nF+2*100nF+2*330nF

Operation Temperature工作温度: -40 + 85ºC

Flame retardant阻燃：UL-94V0

6.L  Impedance阻抗：≥16Ω@500KHz ≥190Ω@30MHz

X  Capacitance容量:2.2nF

Y  Capacitance容量: 2*220nF+2*2.2nF

Operation Temperature工作温度: -40 + 110ºC

Flame retardant阻燃：UL-94V0
